The wire rope, upper clamp and bottom plate of the GS3 arched series stainless steel wire rope isolator are all made of stainless steel;

Full specifications and models, with a load range of 20N~4000N, which is sufficient for the selection of ship electric control boxes, electronic instruments and power auxiliary equipment;

The natural frequency of this series of isolators is 6~10Hz, the damping ratio is greater than 0.18, and the shock isolation is greater than 90%;
The isolator is resistant to oil, seawater, salt spray, sunlight and high and low temperatures (-70℃~260℃), meeting the ship environmental conditions and GJB150.18 ship equipment impact test requirements;

It is suitable for a variety of installation methods such as horizontal placement, side hanging, 45° tilt and suspension; the installation holes can be selected in two forms: threaded holes and light holes;

It is suitable for vibration isolation and impact resistance of electric control equipment and electronic instruments in ships, aerospace, aviation, vehicles and other industries, and can also be used for vibration isolation and impact resistance of power auxiliary equipment such as pumps, fans, motors, engines, etc.
